From when I didn’t know the consequences of meaningless curves.

The following images are from my semester abroad. I would like to know how to make my drawings more substantial, the "information" is all there but drawings are much more than getting the building dimensions across and I would like my drawings to feel more whole?

Meeting House: Prospect + Refuge
Gabe Colombo

#architecture #diagram #plan #section #render
The individual design work seen here was left unfinished after the studio collectively decided to pursue a group design and research project. This meeting house is composed of spaces that offer simultaneous prospect and refuge, paying close attention to the architectural qualities that provide humans with both comfort and connection: intimate space, soft yet legible thresholds, half-walls, and polyrhythmic apertures.

This is a collaboration with Marie Chapa.

These are unfinished/rejected images and drawings that we defined as fragmented crystallization as the division of a whole into modules, allowing the design to atomize in both program and structure.
